0.3M Cable,10Bar,12Vdc,1-5V,Npt1/8 Oil Fuel Diesel Air Gas Water Import Ceramic Pressure Sensor Transmitter Transducer
0.3M Cable,10Bar,12Vdc,1-5V,Npt1/8 Oil Fuel Diesel Air Gas Water Import Ceramic Pressure Sensor Transmitter Transducer
Normaler Preis
€29,38 EUR
Normaler Preis
€0,00 EUR
Verkaufspreis
€29,38 EUR
Inkl. Steuern.
Technical Parameters:
Pressure Range |
0-10bar gauge pressure |
Power Supply |
12VDC |
Signal Output |
1-5V linear voltage output |
Pressure Connection |
NPT1/8 male |
Accuracy |
0.5-1%FS |
Sensor |
Al203-96% ceramic sensor |
Overload Capacity |
200%FS |
Pressure Medium |
Non-corrosive liquid or gas |
Long-term Stability |
0.2%FS/year |
Working Temperature |
-40 to +85℃ |
Temperature Effect on Zero |
Typical:0.02%FS/℃;Maximal:0.05%FS/℃ |
Temperature Drift on Sensitivity |
Typical:0.02%FS/℃;Maximal:0.05%FS/℃ |
Electrical Connection |
Packard Connector with 0.3m cable |
Wiring |
Red:IN+; Black:GND; Green:OUT |
Waterproof Class |
IP65 |
Housing Material |
304 Stainless Steel |
Dimensional Drawing(unit:mm; 1inch=25.4mm):
